034Motorsport Adjustable MQB/MQB Evo Solid Rear Sway Bar Upgrade - Audi 8V/8Y A3,S3,RS3 8S TT,TTS,TTRS,
034Motorsport is proud to offer the ultimate rear sway bar upgrade for the Audi 8V/8Y RS3 and Audi 8S TTRS! The 034Motorsport Adjustable Solid Rear Sway Bar is made from a single piece of high-quality, 0.938 inch thick spring steel for maximum rigidity, and is designed to combat understeer while reducing body roll under hard cornering.
This product was tested thoroughly on the street and track on 034Motorsport's 2018 Audi RS3 and 2018 Audi TTRS Development Vehicles, and multiple enthusiast-owned Audi MQB vehicles before release. The 034Motorsport Adjustable Solid Rear Sway Bar substantially reduces understeer and body roll on 8V Audi RS3 and 8S Audi TTRS vehicles without compromising comfort on the street.
In addition, the 034Motorsport MQB Rear Sway Bar is engineered to be used effectively with the stock front sway bar. No upgrade in the front is required. The addition of a stiffer front bar can positively affect turn-in feel, but ultimately worsens the platform's tendency to understeer. With the stock front sway bar and upgraded 034Motorsport Solid Rear Sway Bar, body roll is virtually eliminated while turn in and off throttle oversteer are greatly improved.
The RS3/TTRS Spec Rear Sway Bar can also be fit onto Volkswagen Mk7/Mk8 Golf R, Mk7 Alltrack, Audi 8V/8Y A3/S3, 8S TT/TTS. The RS3/TTRS Sway Bar will provide increased body roll reduction and improve rigidity even further!
Features:
- Manufactured from high-quality, solid, 0.938” spring steel
- Two positions for adjustability based on driver preference
- Attractive black powdercoat for protection from the elements
- Beautiful billet CNC brackets with clear anodizing for protection from the elements
- Integrated Zerk fittings in the CNC brackets for easy greasing maintenance
- Locating collars to prevent the sway bar from walking side to side
What's Included:
- 034Motorsport 8V Audi RS3 and Audi TTRS Adjustable Solid Rear Sway Bar
- Polyurethane Sway Bar Bushings
- Billet Aluminum Sway Bar Brackets with Integrated Zerk Fittings
- Sway Bar Bracket Installation Hardware Kit
Sway Bar Rate Data:
- 034Motorsport (Soft) - 81% Rate increase vs. factory Audi RS3/TTRS (21.7mm x 3.0mm) hollow rear sway bar
- 034Motorsport (Stiff) - 102% Rate increase vs. factory Audi RS3/TTRS (21.7mm x 3.0mm) hollow rear sway bar
Fitment/Applications:
- Audi A3 2022-Present 8Y MQB-EVO
- Audi A3 2015-2020 8V-MQB
- Audi S3 2022-Present 8Y MQB-EVO
- Audi S3 2015-2020 8V-MQB
- Audi RS3 2015-2017 8V-MQB
- Audi RS3 2018-2020 8V.5-MQB
- Audi RS3 2022+ 8Y
- Audi TT 2016-2023 Mk3-MQB
- Audi TTS 2016-2023 Mk3-MQB
- Audi TTRS 2018-2023 8S-MQB
- Audi RSQ3 2020-Present F3-MQB
- VW Golf R 2022-Present Mk8-MQB-EVO
- VW Golf R 2015-2020 Mk7-MQB
- VW Golf SportWagen 2015-2020 Mk7/Mk7.5
- VW Golf Alltrack 2015-2020 Mk7/Mk7.5
Fits the above models with AWD only
RECOMMENDED ALIGNMENT:
034Motorsport RS3 track use alignment specs; these specifications are optimal for a track driven car with a very "loose" handling attitude and lively rear end that drives towards oversteer. Caution should be used with these alignment specs as they can cause the car to over-rotate and spin, especially during throttle-lift conditions while turning:
- Front: (Tires: 265/35-18 Michelin Sport Cup 2)
- Camber: -3.0 degrees each side (034-601-1013 camber mounts)
- Caster: 7.1 degrees (not adjustable)
- Toe: 0.6mm (toe-in) each side
- Rear: (Tires: 245/40-18 Michelin Sport Cup 2)
- Camber: -1.5 degrees each side
- Toe: 0.8mm (toe-in) each side
